Ceramic Pump Filling And Capping Machine
(1) .Double head ceramic pump is equipped with ceramic plunger. The filling volume and filling speed can be accurately controlled easily.
(2).The special pump head design makes the cleaning and installation very simple, delicate and compact, and easy to carry.
(3)Equipped with double servos for capping two bottles,higher efficiency
(4).Equipped with turntable can mobile filling and capping;
(5). PLC easy to operate. The machine is small and light, easy to carry.
| Items | Parameters | ||||||||||
| Model | LK-02FC | ||||||||||
| Power supply | AC220V 50HZ | ||||||||||
| Power | 400W | ||||||||||
| Filling nozzle quantity | 2（can be customized) | ||||||||||
| Filling pump | Ceramic plunger pump | ||||||||||
| Filling range | 100-1000ul | ||||||||||
| Filling accuracy | ±20ul | ||||||||||
| Capping head | 2 capping heads with servo motor | ||||||||||
| Speed | 2200-2400pcs/H | ||||||||||
| Machine size | 900*650*1000mm | ||||||||||
| Net weight | 105KG |
Samples
 |  |  |
